Ubee Interactive Setting Up and Connecting the EVW32C
Ubee EVW32C Advanced Wireless Voice Gateway Subscriber User Manual • March 2017 14
Place the device in a location that has an operating temperature of 0˚C to 40˚C.
Refer to Understanding Safety and Regulatory Information on page 1 for more
safety information.
3. Power on your PC. The PC must have an Ethernet network adapter or Ethernet port
and an Internet browser installed, such as Firefox or Internet Explorer. The following
browsers are supported:
For Windows 2000, XP, Vista, Windows 8, Windows 7, Google Chrome, Firefox
1.07 and higher, Internet Explorer v7 and above.
For MAC OS X, 10.2, and higher: Firefox 1.07 and higher, Safari 1.x and higher.
4. Plug the power adapter included in the product package into a power outlet, and
connect the other end to the PWR port on the back of the EVW32C.
5. Connect the Ethernet cable included in the product package to your computer’s
Ethernet port. Connect the other end to one of the ETHERNET ports on the back
panel of the EVW32C.
6. Connect a coaxial cable (not included in the product packaging) from the CABLE port
on the back of the device to the cable wall outlet, or to a cable splitter connected to
the wall outlet.
7. Connect an analog telephone (if you will be using the device for telephone service) to
the TEL 1 or TEL 2 port on the back panel of the device. Use the supplied RJ-11
telephone cable for one of the telephones.
8. Validate the network connection using the device LEDs to confirm operations.
The 2.4GHz and 5GHz LEDs must be blinking or solidly lit.
The POWER, DS, US, and ONLINE LEDs are solidly lit.
Refer to Understanding LED Behavior on page 6 for more information.
2.1.1 Wall Mount Installation
You can mount the EVW32C on a wall using the 2 mounting brackets on the side of the
device. Two round or pan head screws are recommended. See the figure below.
Label Size in Millimeters (mm)
A 7.2 +/- 0.5
B 2.6 +/- 0.15
C 19.0 +/- 1.2
