Ublox SARA-G340 ATEX - Page 204

SARA-G3 and SARA-U2 series - System Integration Manual
UBX-13000995 - R26 Appendix
Page 204 of 217
Pin Name
N°
SARA-G3 series
N°
LISA-C2 series
LISA-U1 series
LISA-U2 series
EXT32K
31
SARA-G300/SARA-G310:
32 kHz input for RTC
& low power idle mode
SARA-G340/SARA-G350:
Not Available:
Internal 32 kHz for RTC
& low power idle mode
Not Available:
Internal reference for
low power idle mode
Not Available:
Internal 32 kHz for RTC
& low power idle mode
Not Available:
Internal 32 kHz for RTC
& low power idle mode
32K_OUT
24
SARA-G300/SARA-G310:
32 kHz output, only to
feed the EXT32K input
SARA-G340/SARA-G350:
Not Available
Not Available
Not Available
Not Available
SIM
SIM_CLK
38
1.8V / 3V SIM clock
47
1.8V / 3V SIM clock
(upcoming FW releases)
1.8V / 3V SIM clock
1.8V / 3V SIM clock
SIM_IO
39
1.8V / 3V SIM data
Internal 4.7k pull-up
48
1.8V / 3V SIM data
(upcoming FW releases)
Internal 10k pull-up
1.8V / 3V SIM data
Internal 4.7k pull-up
1.8V / 3V SIM data
Internal 4.7k pull-up
SIM_RST
40
1.8V / 3V SIM reset
49
1.8V / 3V SIM reset
(upcoming FW releases)
1.8V / 3V SIM reset
1.8V / 3V SIM reset
VSIM
41
1.8V / 3V SIM supply
50
1.8V / 3V SIM supply
(upcoming FW releases)
1.8V / 3V SIM supply
1.8V / 3V SIM supply
SIM_DET
42
1.8 V, SIM detect input
Inner pull-down: 103 µA
Not Available
Provided by GPIO5:
1.8 V, SIM detect input
Inner pull-down: 55 µA
Provided by GPIO5:
1.8 V, SIM detect input
Inner pull-down: 200 µA
UART
DSR
6
1.8 V, DSR output
Driver strength: 6 mA
9
Not Available
1.8 V, DSR output
Driver strength: 4 mA
1.8 V, DSR output
Driver strength: 1 mA
RI
7
1.8 V, RI output
Driver strength: 6 mA
10
1.8 V, RI output
Driver strength: 6 mA
1.8 V, RI output
Driver strength: 4 mA
1.8 V, RI output
Driver strength: 2 mA
DCD
8
1.8 V, DCD output
Driver strength: 6 mA
11
Not Available
1.8 V, DCD output
Driver strength: 4 mA
1.8 V, DCD output
Driver strength: 2 mA
DTR
9
1.8 V, DTR input
Internal pull-up: -55 µA
12
Not Available
1.8 V, DTR input
Internal pull-up: -110 µA
1.8 V, DTR input
Internal pull-up: -125 µA
RTS
10
1.8 V, Flow ctrl input
Internal pull-up: -31 µA
13
1.8 V, Flow ctrl input
Internal pull-up: -30 µA
1.8 V, Flow ctrl input
Internal pull-up: -60 µA
1.8 V, Flow ctrl input
Internal pull-up: -240 µA
CTS
11
1.8 V, Flow ctrl output
Driver strength: 6 mA
14
1.8 V, Flow ctrl output
Driver strength: 4 mA
1.8 V, Flow ctrl output
Driver strength: 4 mA
1.8 V, Flow ctrl output
Driver strength: 6 mA
TXD
12
1.8 V, Data input
Internal pull-up: -102 µA
15
1.8 V, Data input
Internal pull-up: -30 µA
1.8 V, Data input
Internal pull-up: -60 µA
1.8 V, Data input
Internal pull-up: -240 µA
RXD
13
1.8 V, Data output
Driver strength: 5 mA
16
1.8 V, Data output
Driver strength: 4 mA
1.8 V, Data output
Driver strength: 4 mA
1.8 V, Data output
Driver strength: 6 mA
UART AUX
TXD_AUX
29
1.8 V, Data input
Internal pull-up: -102 µA
Not Available
Not Available
Not Available
RXD_AUX
28
1.8 V, Data output
Driver strength: 5 mA
Not Available
Not Available
Not Available
USB
VUSB_DET
Not Available
18
5 V, Supply detection
5 V, Supply detection
5 V, Supply detection
USB_D-
Not Available
26
Full-Speed USB 2.0
High-Speed USB 2.0
High-Speed USB 2.0
USB_D+
Not Available
27
Full-Speed USB 2.0
High-Speed USB 2.0
High-Speed USB 2.0
SPI
SPI_SCLK
Not Available
55
Not Available
1.8 V, Clock input
Inner pull-down: 100 µA
1.8 V, Clock input
Inner pull-down: 200 µA
SPI_MOSI
Not Available
56
Not Available
1.8 V, Data input
Internal pull-up: -220 µA
1.8 V, Data input
Internal pull-up: -240 µA
