Ultimaker 3 Extended Cleaning


Clean the feeders and Bowden tubes
After many hours of printing, or when material has been ground down, small filament
particles can build up in the feeder. These can end up in the Bowden tubes or print
cores, which can impact print quality.
Clean the feeders and Bowden tubes at least once a month, or after experiencing an
issue with filament grinding.
Clean the feeders
1.
Remove the material by navigating to
Material/PrintCore > Material [x] > Unload
. After
this, turn off the printer
2.
Blow into the feeder to get the filament particles out. If necessary, use an air blower
or compressed air
Cleaning the Ultimaker 3 – Ultimaker Support https://support.ultimaker.com/hc/en-us/articles/...
3 of 6 12/15/20, 1:51 PM

Ultimaker 3 Extended Specifications

General

Build Volume	215 x 215 x 300 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Operating System	Windows, MacOS, Linux
Print Speed	Up to 24 mm³/s
Software	Ultimaker Cura
Weight	11.3 kg
Print Head	Dual extrusion
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, Nylon, CPE, PVA
Connectivity	USB, Ethernet, Wi-Fi
Display	4.7" color touchscreen
Power Requirements	100 - 240 V / 50 - 60 Hz
Travel Speed	Up to 300 mm/s
