Ultimaker 3 Extended Cleaning

Articles in this section
in the feeder and pushing the Bowden tube all the way in. Secure the tube with the
clamp clip. Repeat this for the other Bowden tube
8.
Insert the Bowden tube into the print head by pressing down on the tube coupling
collet in the print head and pushing the Bowden tube all the way in. Secure the tube
with the clamp clip. Repeat this for the other Bowden tube
Inside of the printer
Small pieces of material can gather inside the printer, such as priming blobs. Remove
these from the inside of the printer with a cloth or vacuum cleaner. Pay extra attention
to the area around the Z limit switch as obstructions here can cause print problems.
Caution:
Leaving larger objects on the bottom panel can lead to errors, as they
prevent the build plate from homing properly.
Was this article helpful?


4 out of 5 found this helpful

Update the Ultimaker 3 firmware

Ultimaker 3 firmware release notes

Replace the build plate clamps of the Ultimaker 3
Cleaning the Ultimaker 3 – Ultimaker Support https://support.ultimaker.com/hc/en-us/articles/...
5 of 6 12/15/20, 1:51 PM

Ultimaker 3 Extended Specifications

General

Build Volume	215 x 215 x 300 mm
Layer Resolution	20 - 200 microns
Print Technology	Fused Filament Fabrication (FFF)
Filament Diameter	2.85 mm
Operating System	Windows, MacOS, Linux
Print Speed	Up to 24 mm³/s
Software	Ultimaker Cura
Weight	11.3 kg
Print Head	Dual extrusion
Nozzle Diameter	0.4 mm
Supported Materials	PLA, ABS, Nylon, CPE, PVA
Connectivity	USB, Ethernet, Wi-Fi
Display	4.7" color touchscreen
Power Requirements	100 - 240 V / 50 - 60 Hz
Travel Speed	Up to 300 mm/s
