Reading Setpoint2 Value
Command : AD0 AD1 2R CHKH CHKL CR
Return format from this unit to PC.
：
AD0 AD1 2 X . X X E ± X X CHKH CHKL CR
 "X.XXE±XX" contains the setpoint value. "±" can be "+" or "-".
Writing setpoint1 value
command : AD0 AD1 1W X . X X E ± X X CHKH CHKL CR
 "X.XXE±XX" contains the setpoint value. "±" can be "+" or "-".
 From 5.00E-08 to 1.00E+05 can be set. If setting a value lower than 5.00E-08,
the value is set to 5.00E-08. If setting a value higher than 1.00E+05, the
value is set to 1.00E+05.
 If the command is received normally, 'o' is returned.
Writing setpoint2 value
Command : AD0 AD1 2W X . X X E ± X X CHKH CHKL CR
 "X.XXE±XX" contains the setpoint value. "±" can be "+" or "-".
 From 5.00E-08 to 1.00E+05 can be set. If setting a value lower than 5.00E-08,
the value is set to 5.00E-08. If setting a value higher than 1.00E+05, the
value is set to 1.00E+05.
 If the command is received normally, 'o' is returned.
Reading mode setting
Command : AD0 AD1 MDR CHKH CHKL CR
Return format from this unit to PC.
：
AD0 AD1 MDR n CHKH CHKL CR
 "n" indicates the following:
「2」: Mode 2 (automatic recognition mode)
「3」: Mode 3 (old output mode：ISG1 S/N:0000 to 04049)
Writing mode setting
Command : AD0 AD1 MDW n CHKH CHKL CR
 "n" indicates the following:
「2」: Mode 2 (automatic recognition mode)
「3」: Mode 3 (old output mode：ISG1 S/N:0000 to 04049)
 If the command is received normally, 'o' is returned.
Reading address setting
Command : AD0 AD1 4AR CHKH CHKL CR
Return format from this unit to PC.
：
AD0 AD1 4AR n n CHKH CHKL CR
"n n" is the set value.
Writing address setting
Command : AD0 AD1 4AW n n CHKH CHKL CR
 "n n" is the set value.
 From 01 to 31 can be set.
 If the command is received normally, 'o' is returned.
