1. Dedicated application
SH200 and ST200 series can check various settings and status using the dedicated
applications below.
Please refer to the application instruction manual for details.
・UL-MOBI_Windows (Supported OS：Windows 10 64bit or later)
・UL-MOBI_Andoroid (Supported OS：Android 6.0 or later)
Download: UL-MOBI_Android Google Play
UL-MOBI_Windows https://www.ulvac.co.jp/download/en/application/
UL-MOBI_Windows Instruction manual
https://www.ulvac.co.jp/download/en/application/
DATA
Check the pressure numerically and draw a
graph.
△ △
DATA LOG
Pressure indication value LOG and CSV
output.
◎ ◎
SAMPLING Check and change the sampling cycle. ◎ ◎
FIL･DEGAS Display filament and DEGAS status. ◎ ◎
Pressure unit Change the pressure unit. ◎ ◎
SETPOINT 1/2/3 Check and change of setpoint. 〇 〇
Baud rate Check and change of baud rate. ● ●
Mode Check and change of mode. ● ●
Address Check and Change of address. ● ●
ATM point
adjust
Adjusts the atmospheric pressure of SAU
and SWU.
▲ ▲
Adjust clear
Reset the zero point and atmospheric
pressure adjustment of SAU and SWU.
▲ ▲
Status Display errors. △ △
New password Changes a password. ◎ ◎
◎：It can be checked and changed at any time
〇：It can be checked at any time. A password is required in order to change
when energized at 24V.
●：It can be checked at any time. It can be changed only when 24V is cut off.
△：It can be done only when energized at 24V.
▲：It can be done only when energized at 24V. A password is required.
※A password is required to change the settings, as careless setting change may cause
the failure of the vacuum system.
The password can be set to any four numbers.
※The software of this unit uses the pressure unit [Pa].
When changing the pressure unit on UL-MOBI, UL-MOBI converts the pressure unit to
[Pa] and writes it to this unit.
Please note that rounding errors may occur when converting units.
