Model UT511: OPERATING MANUAL
The Meter Structure
Below Figure 1 and Table 4 shows the Meter front
structure and description
Figure 1. The Meter Front Structure
1
2
3
4
5
6
7
8
9
10
11
Table 4. Meter Front Description
LCD
Scroll Button
Emergency stop
Data Clear the
Display Backlight
Button,
Down Button
On/Off Button
Compare Button
Insulation Resistance
Button
Voltages
measurement Button
Timer Button.
Low Resistance
measurement Button
12
13
14
15
16
17
18
19
20
21
22
Test Button
Step Button
Data Store Button.
Data Recall Button
Scroll Button
Up Button
LINE: Resistance
input terminal
COM: Voltage input
terminal
EARTH: Resistance
input terminal
V: Voltage input
terminal
Testing leads
