UNI-T UT511 User Manual

10
Model UT511: OPERATING MANUAL
Below Figure 2 and Table 5 shows the Meter side
structure and description
Figure 2. The Meter Side Structure (Side View)
Table 5. Meter Side Description
1 Safety Shutter
2 Power adaptor Input Terminal
Display
Table 6 and Figure 3 describe the display.
Figure 3. Display

UNI-T UT511 Specifications

General

Backlight	Yes
Product type	Digital multimeter
Basic accuracy (DC voltage)	±(1%+3)
Dimensions (WxDxH)	155 x 94 x 202 mm
Battery voltage	1.5 V

Weight and Dimensions

Weight	2000 g
