UNI-T UT511 User Manual

16
Model UT511: OPERATING MANUAL
l When voltage measurement has been completed,
disconnect the connection between the testing
leads and the circuit under test and remove testing
leads away from the input terminals of the Meter.
Note
B. Measuring Insulation Resistance
Figure 5. Insulation Resistance Measurement
Red
Black

UNI-T UT511 Specifications

General

Backlight	Yes
Product type	Digital multimeter
Basic accuracy (DC voltage)	±(1%+3)
Dimensions (WxDxH)	155 x 94 x 202 mm
Battery voltage	1.5 V

Weight and Dimensions

Weight	2000 g
