UNI-T UT60A User Manual

Maintenance (3)
2. Remove the screw from the battery compartment,
and separate the battery compartment from the case
bottom.
3. Remove the battery from the battery compartment.
4. Replace the battery with a new 9V battery
(NEDA1604, 6F22 or 006P).
5. Rejoin the case bottom and battery compartment,
and reinstall the screw.
D. Replacing the Fuses (see figure 12)
(figure 12)
Rubber foot
Screw
Warning
To avoid electrical shock or arc blast, or personal
injury or damage to the Meter, use specified fuses
ONLY in accordance with the following procedure.
To replace the Meter's fuse:
1. Press the POWER to turn the Meter off and remove
all connections from the terminals.
2. Remove the screw from the battery compartment,
and separate the battery compartment from the case
bottom.
3. Remove the 2 rubber feet and 2 screws from the
case bottom, and separate the case top from the
case bottom.
4. Remove the fuse by gently prying one end loose,
and then take out the fuse from its bracket.
Model UT60A: OPERATING MANUAL
39

UNI-T UT60A Specifications

General

Data hold	Yes
Product type	Digital multimeter
Frequency range	0.01 - 10000 kHz
AC current range	0.4 - 10 A
AC voltage range	4 - 750 V
DC voltage range	0.4 - 1000 V
Dimensions (WxDxH)	85 x 177 x 40 mm
Battery voltage	9 V

Weight and Dimensions

Weight	340 g
