25
Measurement Operation(9)
Warning
To avoid harms to you, please do not attempt to
measure voltages higher than 60V DC or 30V rms AC.
To avoid damages to the Meter or to the devices
under test, disconnect circuit power and discharge
all the high-voltage capacitors before measuring
continuity.
To test for continuity, connect the Meter as follows:
1. Insert the red test lead into the HzVΩ terminal and
the black test lead into the COM terminal.
2. Set the rotary switch toΩ and press BLUE button
to select measurement mode.
3. The buzzer sounds if the resistance of a circuit under
test is less than 70Ω, The LCD simultaneous displays
the two ends' of the tested circuit resistance value.
Note
l The LCD displays OL indicating the circuit being
tested is open.
l The testing range of continuity is fixed as:
UT60F: 400.0Ω
UT60G: 600.0Ω
The open circuit voltage approximate 1.2V.
l When continuity testing has been completed,
disconnect the connection between the testing leads
and the circuit under test and remove testing leads
from the input terminals.
Model UT60F/G: OPERATING MANUAL
