37
Warning
To avoid false readings, which could lead to possible
electric shock or personal injury, replace the battery
as soon as the battery indicator “ ” appears.
Make sure the test leads are disconnected from the
circuit being tested before opening the case bottom.
To replace the battery:
l Press the POWER to turn the Meter off and remove
all connections from the terminals.
l Remove the screw from the battery compartment,
and separate the battery compartment from the case
bottom.
l Remove the battery from the battery compartment.
l Replace with a new 9V battery (NEDA 1604 or 6F22
or 006P) .
l Rejoin the case bottom and battery compartment,
and reinstall the screw.
C. Replacing the Fuses (see figure 13)
Maintenance(2)
Rubber foot
Screw
( figure 13)
Model UT60F/G: OPERATING MANUAL
