38
Warning
To avoid electrical shock or arc blast, or personal
injury or damage to the Meter, use specified fuses
ONLY in accordance with the following procedure.
To replace the Meter’s fuse:
l Press the POWER to turn the Meter off and remove
all connections from the terminals.
l Remove the screw from the battery compartment,
and separate the battery compartment from the case
bottom.
l Remove the 2 rubber feet and 2 screws from the
case bottom, and separate the case top from the
case bottom.
l Remove the fuse by gently prying one end loose,
then take out the fuse from its bracket.
l Install ONLY replacement fuses with the identical
type and specification as follows and make sure the
fuse is fixed firmly in the bracket.
Model UT60F:
Fuse 1: 0.5A, 250V, fast type fuse, ø5×20mm
Fuse 2: 10A, 250V, fast type fuse, ø5×20mm
Model UT60G:
Fuse 1: 1A, 250V, fast type fuse, ø5×20mm
Fuse 2: 10A, 250V, fast type fuse, ø5×20mm
l Rejoin the battery compartment and the case top,
and reinstall the screw.
l Rejoin the case bottom and case top, and install the
2 screws and 2 rubber feet.
Replacement of the fuses is seldom required. Burning
of a fuse always results from improper operation.
Maintenance(3)
Model UT60F/G: OPERATING MANUAL
