UNI-T UT60F - Resistance; Diode Test; Continuity Test

34
Model UT60F at 10.00A range:
10A, 250V, fast type fuse, ø5×20mm
Model UT60G at 60.00mA to 600.0mA range:
1A, 250V, fast type fuse, ø5×20mm
Model UT60G at 10.00A range:
10A, 250V, fast type fuse, ø5×20mm
l At 10.00A range:
For continuous measurement 10 seconds and
interval time between 2 measurements greater than
15 minutes.
l Frequency response: 40Hz~1kHz.
E. Resistance
F. Diode Test
Remarks:
l Open circuit voltage approximate 3V.
l Display forward voltage drop approximate 0.5~0.8V.
G. Continuity Test
Range Resolution Overload Protection
600Vp
1Ω
Range Resolution Overload Protection
600Vp
10mV
Remark:
l Open circuit voltage approximate 1.2V.
Range
Resolution
Accuracy
(1.2%+2)
UT60F UT60G
Remarks
400.0Ω
600.0Ω
Open circuit
voltage
approximate
1.20V
4.000kΩ
40.00kΩ
400.0kΩ
4.000MΩ
40.00MΩ
6.000kΩ
60.00kΩ
600.0kΩ
6.000MΩ
60.00MΩ
0.1Ω
1Ω
10Ω
100Ω
1kΩ
10kΩ
(1%+2)
(1.2%+2)
(1.5%+2)
Open circuit
voltage
approximate
0.45V
Accuracy Specifications(3)
Model UT60F/G: OPERATING MANUAL
