Measurement Operation(12)
The measurement ranges are:
Model UT60F: 4kHz, 40kHz, 400kHz, 4MHz and
40MHz.
Model UT60G: 6kHz, 60kHz, 600kHz, 6MHz and
60MHz.
To measure frequency, connect the Meter as follows:
1. Insert the red test lead into the HzVΩ terminal
and the black test lead into the COM terminal.
2. Set the rotary switch to Hz;
3. Connect the test leads across with the object
being measured.
The measured value shows on the display.
Note
l When measuring input scope < 30V rms
frequency signal, follow the above procedure.
When measuring input scope >30V rms,
reading may not be obtained due to the
fluctuation of overload protection circuit.
l The test lead has distributed capacitors
during measurement, it has more attenuate
effect against high frequency. Therefore,
when testing higher than 1MHz frequency
signal, it is recommended to use a high and
as short as possible frequency transmit cable
carrying out the testing.
l When Hz measurement has been completed,
disconnect the connection between the testing
leads and the circuit under test and remove
the testing leads away from the input terminals.
Model UT60F/G: OPERATING MANUAL
