Model UT805: OPERATING MANUAL
F. Diode Test
Range Measurement Scope Resolution Overload Protection Remarks
0.00~6.00V 10mV 250Vp
Open circuit voltage approximate 2.8V.
A good silicon junction drops between
0.5V and 0.8V
l
l
Range Measurement Scope Resolution Overload Protection Remarks
l
l
l
G. Continuity Test
0~600 250Vp1
Open circuit voltage approximate -1.2V.
When circuit disconnected with
resistance value 50 , buzzer does
not beep.
When circuit is in good connection with
resistance value 10 , buzzer beeps
continuously.
To Next Page
