33
1.
2.
3.
Model UT805: OPERATING MANUAL
COM
Hz
Hz
H. Frequency Measurement (see figure 12)
Warning
To avoid harms to you, please do not attempt to input
voltages higher than 60V DC or 30V AC.
To measure frequency, connect the Meter as follows:
Insert the red test lead into the terminal
and the black test lead into the COM terminal.
Press Hz button to select frequency measurement
mode. Auto ranging is default.
Connect the test leads across with the object being
measured.
The measured value shows on the primary display
and the secondary display shows the cycle of the
tested frequency.
(figure 12)
