UTD1000 User Manual
Video Trigger
Trigger sensitivity (video trigger, typical)
2 div peak-to-peak signal format and line/
field frequency (video trigger type)
A Trigger
B Trigger
Alternate Trigger
2 div peak-to-peak
Supports standard NTSC and PAL
Line range : 1-525 (NTSC) and 1-625 (PAL)
Edge, pulse, video
Edge, pulse, video

