UTD1000 User Manual
Measurement
Cursor
Automatic
measurement
Customized parameter
measurement
Math functions
Saving waveforms
FFT
Lissajous Figure
Manual mode
Cursor display is allowed during auto measurement.
Total 27 measurements : peak-to-peak, amplitude, maximum, minimum, top,
bottom, mean, average, root mean square, overshoot, preshoot, frequency,
cycle, rising time, falling time, positive pulse, negative pulse, positive duty ratio,
negative duty ratio, rise delay, fall delay.
3 types
ˇˉ
×, ÷ ,
Internal : 10 groups of waveforms and 10 setups.
USB : 10 groups of interfaces, 10 groups of waveforms.
Window
Sampling points
Phase difference
Voltage difference (
Ƹ
V) between cursors, time
difference (
Ƹ
T) between cursors.
Hanning, Hamming, Blackman-Harris, Rectangular
1024 points
± 3 degrees
