User's arbitrary wave, Delete
Select the UtilityToolArbMngUserOK, Other List to select arbitrary wave to delete, for
example”ABA_1_2.bsv”,Select Delete, the arbitrary wave is deleted.
User's arbitrary wave, Delete current page
Select the Utility  Tool  ArbMng User  OK, Select Delete Page, the arbitrary wave of the current page
is deleted.
User's arbitrary wave, Delete all
Select the Utility  Tool ArbMng  User OK, Select Delete All, the arbitrary wave in the current folder
is deleted.
User's arbitrary wave, Export
Select the Utility Tool ArbMng  User  OK, Select the arbitrary waveform that needs to be exported
in the “Other” list, such as "ALT_03.bsv", Select Export, the arbitrary wave is exported to an external storage
device.
User's arbitrary wave, Export All
Select the Utility ToolArbMng Interna OK, Select Export ALL, the arbitrary wave in the current
folder is exported to the external storage device.
External arbitrary wave, Import
Select the Utility  Tool ArbMng  External  OK, select an arbitrary wave directory, press rotary knob,
open the arbitrary wave list, List to select arbitrary wave to import, for example”ABA_1_2.bsv”, Select Import,
the arbitrary wave is imported into this arbitrary wave manager in the user directory.
External arbitrary wave, Import current page
Select the Utility  Tool  ArbMng  External OK, select an arbitrary wave directory, press rotary knob,
open the arbitrary wave list, Select Import Page, the arbitrary wave of the current page is imported into this
arbitrary wave manager in the user directory.
External arbitrary wave, Import All
Select the UtilityTool  ArbMng External  OK, select an arbitrary wave directory, press rotary knob,
open the arbitrary wave list, Select Import All, the all arbitrary wave in the current folder is imported into this
arbitrary wave manager in the user directory.
