User’s Manual UTG1000X Series
Instruments.uni-trend.com 67 / 74
Appendix A Factory Setting
Parameter
Factory Default Setting
Channel Parameter
Current Carrier Wave
Sine wave
Output On-load
High
Sync Output
OFF
Channel Output
OFF
Channel Output Reverse
OFF
Amplitude Limit
OFF
Upper Limit of Amplitude
+10 V
Lower Limit of Amplitude
-10 V
Fundamental Wave
Frequency
1 kHz
Amplitude
100 mVpp
DC Deviation
0 mV
Start Phase
Duty Cycle of Square Wave
50%
Symmetry of Ramp Wave
50%
Duty Cycle of Pulse wave
50%
Rising edge of Pulse wave
15ns
Falling edge of Pulse wave
15ns
Arbitrary Wave
Built-in Arbitrary Wave
AbsSine
AM
Modulation Wave
Sine wave
Modulation Frequency
100 Hz
Modulation Depth
100%
FM
Modulation Wave
Sine wave
Modulation Frequency
100 Hz
