UNI-T UTG1000X Series User Manual

User’s Manual UTG1000X Series
Instruments.uni-trend.com 18 / 74
Select UtilityCH1 Setting （or CH2 Setting）to set the channel.
1. Channel Output
Select Channel Output, it can select “OFF” or “ON”.
Notes: Press CH1, CH2 key on the front panel to quick enable the channel output.
2. Channel Reverse
Select Channel Reverse, it can select “OFF” or “ON”.
3. Sync Output
Select Sync Output, it can select “CH1”, “CH2” or “OFF”.
4. On-load
Select Load, input range is 1Ω to 999Ω, or it can select 50Ω, high impedance.
5. Amplitude Limit
It supports amplitude limit output to protect on-load. Select Amp Limit, it can select “OFF” or “ON”.
6. Upper limit of Amplitude
Select Upper to set the upper limit range of the amplitude.
7. Lower limit of Amplitude
Select Lower to set the lower limit range of the amplitude.
3.2.2 Frequency Meter
This function/arbitrary waveform generator can measure the frequency and duty cycle of compatible TTL
level signals. The range of measurement frequency is 100mHz～200MHz. When use the frequency meter, the
compatible TTL level signal is input via external digital modulation or frequency meter port (FSK /CNT/Sync
connector).
Select UtilityFrequency Meter to read “frequency”, “period” and “duty cycle” value of the signal in the
parameter list. If there is no signal input, the parameter list of the frequency meter is always display the last
measured value. The frequency meter will only refresh the display if a TTL level compatible signal is input via
an external digital modulation or frequency meter port (FSK/CNT connector).
3.2.3 Arbitrary wave manager
Delete, export, and import arbitrary wave from the built-in and external storage devices.
Local arbitrary wave, View
Select the UtilityTool  ArbMng  Local OK  Other OK, All arbitrary waves in the Other list can be
browsed.
