UNI-T UTG1000X Series User Manual

User’s Manual UTG1000X Series
Instruments.uni-trend.com 11 / 74
Chapter 2 Introduction of UTG1000X Series
This product has DDS (direct digital frequency synthesis) function, it can generate high precision and stable
waveform output with a resolution as low as 1μHz. It is an economical, high performance, multifunction
function/arbitrary waveform generator. It can generate high precision, stable, pure and low distortion signal.
UTG1000X series has convenient operation, superior technical indicators and humanized graphics display. A
multi-purpose equipment for the needs of learning, testing and improving work efficiency.
2.1 Main Features
 Frequency output of 40MHz/20MHz, 1μHz resolution of full frequency band
 DDS function, it has 200MSa/s sampling rate and 16-bit vertical resolution
 Square wave with the maximum frequency 20MHz, low jitter
 Multiple analog and digital modulation function: AM, FM, PM, ASK, FSK, PSK and PWM
 Supporting sweep frequency and pulse string output
 Arbitrary wave can generate by the upper software computer
 Built-in power pre-amplifier, the maximum power output 4W (only for-PA model)
 7 bit hard frequency meter
 Built-in 200 arbitrary waves
 Standard USB Host and USB Device
 4.3 inch high resolution TFT LCD
2.2 Output Features
Channel
CH1,CH2
Amplitude Range
1mVpp～10Vpp（50Ω）
Waveform
Sine wave, square wave, pulse wave, ramp wave, arbitrary wave, noise,
DC
Modulation
AM, FM, PM, ASK, FSK, PSK, PWM
Sweep Frequency
Log，Line

UNI-T UTG1000X Series Specifications

General

Brand	UNI-T
Model	UTG1000X Series
Category	Portable Generator
Language	English
