Frequency Deviation
1 kHz
PM
Modulation Wave
Sine wave
Modulation Frequency
100 Hz
Phase Deviation
180°
ASK
ASK Rate
100 Hz
FSK
Modulation Source
Internal
FSK Rate
100 Hz
Hopping Frequency
10 kHz
PSK
Modulation Source
Internal
PSK Rate
100 Hz
Phase
180°
PWM
Modulation Wave
Sine wave
PWM Rate
100 Hz
Duty Cycle
20%
Frequency Sweep
Frequency Sweep Type
Linear
Start Frequency
1 kHz
Stop Frequency
20 kHz
Sweep Time
100 ms
Pulse String
Trigger Source
Internal
Start Phase
0°
Polarity
Positive
