SectMod
（5 types）
FM
Sine wave frequency modulation
PFM
Pulse frequency modulation
PM
Sine wave phase modualtion
PWM
Pulse width modualtion
Bioelect
（6 types）
Cardiac
Electrocardio signal
EOG
Electro-oculogram
EEG
Electroencephalogram
EMG
Electromyography
Pulseilogram
Sphygmograph of common people
ResSpeed
Expiration speed curve of common
people
Medical
（4 types）
LFPulse
Low frequency pulse electrotherapy
waveform
Tens1
Transcutaneous electric nerve
stimulation waveform 1
Tens2
Transcutaneous electric nerve
stimulation waveform 2
Tens3
Transcutaneous electric nerve
stimulation waveform 3
Standard
(17 types)
Ignition
Ignition waveform of automobile
internal-combustion engine
ISO16750-2 SP
Profile map of automobile starting
oscillation
ISO16750-2 Starting1
Automobile starting voltage waveform 1
ISO16750-2 Starting2
Automobile starting voltage waveform 2
ISO16750-2 Starting3
Automobile starting voltage waveform 3
ISO16750-2 Starting4
Automobile starting voltage waveform 4
ISO16750-2 VR
Profile map of the reset working voltage
ISO7637-2 TP1
Transient phenomena of automobile
caused by power cut
ISO7637-2 TP2A
Transient phenomena of automobile
caused by inducatance in wiring
ISO7637-2 TP2B
Transient phenomena of automobile
caused by turning off start-up changer
ISO7637-2 TP3A
Transient phenomena of automobile
caused by conversion
ISO7637-2 TP3B
Transient phenomena of automobile
caused by conversion
ISO7637-2 TP4
Working profile map of automobile in
start-up
ISO7637-2 TP5A
Transient phenomena of automobile
caused by power cut of battery
ISO7637-2 TP5B
Transient phenomena of automobile
caused by power cut of battery
SCR
SCR sintering temperature distribution
