Unic Tango Ace User Manual

54
►Active components
OPTION LC
SM1 Co󰀨ee safety system, grinder no 1
SM2 Co󰀨ee safety system, grinder no 2
SM3 Co󰀨ee safety system, grinder no 3
SM4 Co󰀨ee safety system, grinder no 4
CHU Moisture sensor
CPV Steam pressure sensor
CPR Mains pressure sensor
MGET1 Coin acceptor no 1 micro switch
MGET2 Coin acceptor no 2 micro switch
SNB Low level probe
SNH High level probe
THV Steam boiler thermostat probe
THG Group thermostat probe
THK Co󰀨ee boiler thermostat probe
CO. D Encoder, right cylinder
PB. D Right cylinder low position
EVK.D Right co󰀨ee SV
EVAE.D SV add water at co󰀨ee outlet, right
EVINF.D Infusion D (cleaning) SV
EVS2
EVC.D Cappuccino from the LC outlet, right SV
EVL.D Latte from the LC outlet, right SV
MM1 Mixer motor 1
MM2 Mixer motor 2
MT1 Bin 1 motor
MT2 Bin 2 motor
SFAN Soluble fan
SMAN Manual door safety system
SEA Water presence safety system
SNK Plug safety system for the group cleaning circuit
DO. D Right volumetric meter
DO. G Left volumetric meter
DO. E Hot water outlet volumetric meter
CO. G Encoder, left cylinder
PP. D Tray position to the right
PP. G Tray position to the left
PB. G Left cylinder low position
EA.MAN Manual door electro-magnet
RSV1 Static steam relay 1
RSV2 Static steam relay 2
RSV3 Static steam relay 3
RSC1 Static co󰀨ee relay 1
