17
ENGLISH
Installation Instructions
3.6 - FLUE GAS EXHAUST PIPE CONNECTION
To connect the ue gas exhaust pipe, local and na-
tional standards must be observed
(3%) slope towards inlet
LINEAR LENGTH
COAXIAL Ø60/100 DOUBLE Ø80
FROM
[m]
UP TO
[m]
FROM
[m]
(2)
UP TO
[m]
(1) (3)
1
(2)
5.5
(1)
0.5 - 0.5 46
LINEAR LENGTH
COAXIAL Ø60/100 DOUBLE Ø80
FROM
[m]
UP TO
[m]
FROM
[m]
(2)
UP TO
[m]
1
(2)
7
(1)
0.5 - 0.5 46
(1) (5)
COAXIAL Ø80/125 DOUBLE Ø60
FROM
[m]
UP TO
[m]
FROM
[m]
(2)
UP TO
[m]
(1) (4)
1
(2)
8
(1)
0.5 - 0.5 29
Horizontal exhaust and intake terminals directed
outside via coaxial or double pipes.
COAXIAL Ø80/125 DOUBLE Ø60
FROM
[m]
UP TO
[m]
FROM
[m]
(2)
UP TO
[m]
1
(2)
9
(1)
0.5 - 0.5 29
(1) (6)
Vertical exhaust and intake terminals directed
outside via coaxial or double pipes.
C13
C33
FOR BOILERS WITH FORCED DRAUGHT
In the event the boiler is replaced, ALWAYS re-
place the ue gas pipe as well.
The boiler is type approved for the exhaust congu-
rations listed below:
(1) Excluding terminal/s and possible 90° bend/and
in the event of double pipes it means
excluding splitter, wide radius bends, terminals
(2) Only terminal/s and possible 90° bend/and
in the event of double pipes it means including
splitter wide radius bends
Note for double pipes:
The total length is meant as the sum of the intake and
exhaust pipes
(3) The longest pipe in any case must not
exceed a distance of 20 m from the appliance
(4) The longest pipe in any case must not
exceed a distance of 10 m from the appliance
(5) The longest pipe in any case must not
exceed a distance of 15 m from the appliance
(6) The longest pipe in any case must not
exceed a distance of 10 m from the appliance
