HX120
Identify the unit
The naming rule of these units is based on the
MAC address which labeled on the bottom of
the devices. For example, if the MAC address of
Transmitter is 00:11:AA:CB:00:01, the device will
be named to HX120T-CB0001. T is for Transmitter,
R is for Receiver and W is for Video Wall.
IP address assignment
If the PC cannot access the Transmitter and
Extender Receiver/VideoWall Receiver using web
UI, please follow the steps below to join the PC
to the network.
Note: The example shown here is using Windows 7. For
other operating systems, please refer to the respective user
guides.
1. Click Control Panel to bring up Adjust your
computer's settings window, and then click
Network and Internet item.
2. Click Network and Sharing Center.
3. Click Change adapter settings from left side.
4. Click Local Area Connection.
5. Mouse right click Local Area Connection to
bring up a pop-up window, and then select
Properties.
