HX120
Basic operation
1. Press Menu button to bring up the device ID.
HX120W-D0001C
Select Channel
About
Select Channel
Scan node
HX120T-C80006
HX120T-C80007
[HX120T-C80008]
HX120T-C80009
HX120W-D0001C
Step2 Step3 Step4
2. The device ID will appear on the screen. To specify the desired device, press Left or Right button. Once
the device has been confirmed, press OK to bring up more options.
3. Select Select Channel, and then press OK.
4. The available sources will be listed on the screen. Press Up or Down button to select the desired
source, and then press OK.
5. The screen will display to the new source you have selected.
Additional options
■
Select Scan node to refresh if more devices have been connected.
■
Select About to show the firmware version.
HDMI CEC
Except the remote control (optional), remote the device through HDMI CEC is supported as well. The
operation is similar with the remote control described above. Note that the definition of Menu button
on the remote control and name of HDMI CEC may vary (for example, Bravia sync control, VieraLink,
Kuro Link, Aquos Link, etc.). For more details, please refer to the corresponding instruction manual or
manufacturer.
