12 General information
Icons used in the manual
Tips
z Refers to a setting established via the web-interface.
Displays for describing operation
Selected action
Original illustration on display
Step-by-step illustration in the User Guide
A dark background is not used in the step-by-step illustration in order to ensure
legibility in the User Guide.
The information area on the left is shown in a left-aligned field.
When an action is selected, it will be shown right-aligned in green. The action is
executed by selecting the softkey.
Z The selected function can alternatively be confirmed using the Z key on the
navigator (ïƒ page 23).
Indicates additional important information in relation to handling.
ñ
Indicates required intervention by the administrator.
Andre-Marie Ampere
3336
Consultation
o
_
