2
Table of Contents
Installation Environment Page 3
IColor 560 Model Summary Page 3
Machine Guide Page 4 - 8
Unpacking and Installing Consumables Page 9 - 11
Loading Paper Page 12 – 15
Cable Connections Page 16
Wireless Setup Page 16 - 20
IColor ProRIP Software Introduction Page 21 - 26
IColor ProRIP First Time Setup Page 26 - 31
Using the IColor ProRIP Software Page 32 - 36
Toner Cartridge Replacement Guide Page 37
Use Genuine UNINET IColor Consumables Page 37
Printing with Fluorescent and Dye Sublimation Toner Page 38
IColor SmartCUT Information Page 39
Replacing the Print Cartridges Page 39 - 41
Replacing the Waste Toner Bottle Page 42 - 44
Cleaning the Toner Density Sensor and LD Unit Dust Shield Page 44 - 45
Cleaning the Registration Roller Page 45
Cleaning the Paper Tray, Friction Pad and Paper Feed Roller Page 46
Removing Paper Jams Page 46 - 48
Replacing the Fusing Unit Page 49
IColor 560 Printing Tips Page 50
Available transfer paper and media options Page 51
IColor 560 System Specifications Page 52
Important note about USB Drives shipped with your system: Do not lose or break your RIP dongle!
This is your license key and if lost, a cost for replacement will be incurred. Associated USB dongles
for software such as drivers, RIP programs, SmartCUT and more have a 3 month warranty on the
physical drive. UNINET suggests that you limit the physical handling of RIP dongles and use external
USB hubs (as an example). If damaged (past the 3 month warranty period), a cost for replacement
will be incurred.
April 2021 Edition – A newer version of this manual may be available at www.icolorprint.com/support
