Unitech MS836 User Manual

W086B08
W086B00
*Transmit UPC-A Check Digit
Do Not Transmit UPC-A
Check Digit
Check Digit Verification
Example: Set the scanner for check digit
Interleaved 2 of 5.
A check digit is optional for Interleaved 2 of 5 and can
be added as the last digit. It is a calculated value
used to verify the integrity of the data.
Disable: The scanner transmits Interleaved 2 of 5
barcodes as is.
Do Not Transmit Check Digit After Verification:
The scanner checks the integrity of all Interleaved
2 of 5 barcodes to verify that the data complies
with the check digit algorithm. Barcodes passing
the check will be transmitted except the last digit,
whereas those failing it will not be transmitted.
Transmit Check Digit After Verification: The scanner
checks the integrity of all Interleaved 2 of 5
barcodes to verify that the data complies with the
check digit algorithm. Barcodes passing the check
will be transmitted, whereas those failing it will not
be transmitted.

Unitech MS836 Specifications

General

Type	Handheld bar code reader
Wavelength	650 nm
Sensor type	Laser
Scanner type	1D
Read rate (max)	100 reads/s
Maximum scan area	220 x 250 mm
Maximum scan width	220 mm
Linear (1D) barcodes supported	Codabar, Code 128, Code 39, EAN-13, EAN-8, GS1-128 (UCC/EAN-128), Interleaved 2 of 5, MSI, U.P.C.
2D (matrix & stacked) barcodes supported	Not supported
Standard interfaces	USB
Connectivity technology	Wired
Power consumption	85 mA
Buzzer	Yes
Certification	CE, FCC
Product color	Black
Housing material	Plastic
International Protection (IP) code	IP42
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 45 °C
Operating relative humidity (H-H)	5 - 85 %

Weight and Dimensions

Depth	95 mm
Width	70 mm
Height	160 mm
Weight	150 g
