Unitech MS842P User Manual

26
GUI Key Keystroke
3089 GUI Y
3090 GUI Z
Note: GUI Shift Keys - The Apple™ iMac
keyboard has an apple key on either
side of the space bar.
Windows-based systems have a GUI key to the
left of the left ALT key, and to the right of the
right ALT key.
USB F Key Character Set
F Keys Keystroke
5001 F1
5002 F2
5003 F3
5004 F4
5005 F5
5006 F6
5007 F7
5008 F8
5009 F9
5010 F10
5011 F11
5012 F12
5013 F13
5014 F14
5015 F15
5016 F16
5017 F17
5018 F18
5019 F19
5020 F20
5021 F21
5022 F22
5023 F23
5024 F24

Unitech MS842P Specifications

General

Type	Handheld bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Tilt reading angle	-60 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 25 (IR 2 of 5), Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, MSI, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
USB version	2.0
Wireless range	10 m
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Product color	Black, Grey, Yellow
Housing material	-
International Protection (IP) code	IP54
Battery life	10 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1620 mAh
Power consumption	400 mA
Power source type	DC
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	74 mm
Width	89 mm
Height	176 mm
Weight	200 g
Base dimensions	73 x 95 x 200 mm
