Unitech MS842P User Manual

vi
Table of Contents
PREFACE
ABOUT THIS MANUAL .............................................................................................................. I
Regulatory Compliance Statements .................................................................................... ii
FCC Warning Statement ...................................................................................................... ii
FCC Label Statement ........................................................................................................... ii
RF Radiation Exposure Statement ....................................................................................... ii
Canadian Compliance Statement ......................................................................................... ii
European Conformity Statement ......................................................................................... iii
RoHS Statement ................................................................................................................. iii
Taiwan NCC Warning Statement ......................................................................................... iii
Laser Information ................................................................................ 錯誤! 尚未定義書籤。
Battery Notices .................................................................................................................... iv
Battery charge notice .......................................................................................................... iv
Storage and safety notice .................................................................................................... iv
Warranty ................................................................................................................................ v
CHAPTER 1
OVERVIEW ................................................................................................................................ 1
Introducing the MS842P ....................................................................................................... 1
Report Version .................................................................................................................... 2
Package Contents ................................................................................................................. 2
CHAPTER 2
BATTERY CHARGING AND CONNECTION ............................................................................. 5
Connecting a USB Interface, Dongle Mode ........................................................................ 5
Dongle Mode (with SCM support) ....................................................................................... 5
Connecting a USB Interface, Cradle Mode ......................................................................... 6
Cradle Mode (without SCM support) ................................................................................... 6
LED / Beeper Indication for Scanner ................................................................................... 9
LED Indication for Scanner ................................................................................................. 9
Beeper Indication for Scanner ............................................................................................. 9

Unitech MS842P Specifications

General

Type	Handheld bar code reader
Sensor type	CMOS
Scanner type	1D/2D
Tilt reading angle	-60 - 60 °
Linear (1D) barcodes supported	Codabar, Code 11, Code 128, Code 25 (IR 2 of 5), Code 39, Code 93, EAN-13, GS1-128 (UCC/EAN-128), JAN, MSI, Telepen, Trioptic, U.P.C.
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, Data Matrix, MaxiCode, Micro QR Code, PDF417, QR Code, TLC-39
USB version	2.0
Wireless range	10 m
Operating frequency	2400 MHz
Standard interfaces	Bluetooth, USB
Connectivity technology	Wired & Wireless
Certification	CE, FCC, BSMI, VCCI
Product color	Black, Grey, Yellow
Housing material	-
International Protection (IP) code	IP54
Battery life	10 h
Charging time	4 h
Input voltage	5 V
Battery capacity	1620 mAh
Power consumption	400 mA
Power source type	DC
Storage temperature (T-T)	-30 - 70 °C
Operating temperature (T-T)	0 - 50 °C
Operating relative humidity (H-H)	5 - 95 %

Weight and Dimensions

Depth	74 mm
Width	89 mm
Height	176 mm
Weight	200 g
Base dimensions	73 x 95 x 200 mm
