Unitech PA500 User Guide

31
NOTE: If ActiveSync doesn’t start automatically, click Start >
Programs > Microsoft ActiveSync > File > Connection Settings >
Connect > OK.
If a message appears indicating that it is unable to detect a
connection, click the Cancel button and manually configure the
communication settings.
5 Follow the onscreen instructions.
6 When the configuration process is complete, the ActiveSync window
appears.
7 Synchronization will be initialized and will take place if you’ve chosen
to synchronize periodically or upon connection.
NOTE: Your computer can create a partnership with multiple PA500.
Also, the PA500 can create a partnership with up to two computers.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
