Unitech PA500 User Guide

77
Chapter 6 Regulatory and Safety Notices
This chapter lists the specifications and regulatory and safety notices of
PA500.
System Specifications
CPU/Memory
CPU Intel PXA270 processor with speed of up to 520 MHz
Flash ROM 64 MB Built-in (Flash Memory Manager included)
SDRAM 64 MB
Input/Output
Input Devices • Touch screen
•Stylus
• Control buttons
• Full alphanumeric software keyboard
• Mag stripe reader
• Barcode scanner
Control and Quick
launch hot keys
• Navigation key
• Software keyboard button
• Email button
• Today button
• Calendar button
• Tasks button
• Notes button
Audio • Built-in speaker
• 3.5 mm stereo earphone jack
• Microphone
Display • 3.5” QVGA LCD touch-sensitive screen and
Electroluminescent backlight
• 320 x 240 resolution
LED Indicator Dual colors (green/red) for barcode read indication

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
