Unitech PA500 User Manual

Unitech Electronics Co., Ltd Created
by Yukiko
PA500 Operation
Manual
V2.0 Page 88 of 123
7. Obtain the following information from your network administrator: server phone
number, username and password. Under “My Work Network”, tap “Add a new
modem connection”,
8. Repeat step 3 ~ step 6 to add a new connection.
9. Under “My Work Network”, tap “Add a new VPN server connection”. Enter the
name for the connection. Enter the VPN server name or IP address. Select the type of
VPN to use with your device. Tap “Next”. Select the type of authentication. If you
select “A pre-shared key”, enter the key provided by your network administrator.
Tap “Next”. Enter the username, password and domain name. Tap “Finish”.

Unitech PA500 Specifications

System Memory

SDRAM	64 MB
Flash ROM	64 MB

Display

display resolution	240x320 QVGA
display type	Color Transflective TFT
touch screen	yes

Laser Bar Code Scanner

scan rate	104 scans/sec ± 12 scans/sec
scan angle default	47°±3°
scan angle reduced	35°±3°

Power

main battery voltage	3.7 V
main battery capacity	2200 mAh
rechargeable time	3.5 hours

Operating Environment

operating temperature	32°F to 122°F (0°C to 50°C)
storage temperature	-4°F to 140°F (-20°C to 60°C)
relative humidity	5% ~ 95% (non-condensing)

Weight and Dimensions

weight with battery and scan engine	Under 213 g
length	126 mm
height	23 mm
