Unitech PA692 User Manual

- 8 -
2. Push up the backup battery switch
to the “ON position by using
a stylus to turn on the backup
battery.
3. Slide and position the battery
pack, making sure the battery
contacts are aligned with the
contacts in the compartment.
4. Use your thumb to snap the
battery in place.
5. Replace the battery compartment
cover by pushing down on the
tabs and sliding them back into
place as shown.
NOTE: Make sure the battery compartment cover is securely closed, or you
may be unable to turn ON the terminal.
Backup Battery
Switch
Battery
Compartment
Contacts
Plastic Tab

Unitech PA692 Specifications

General

Touchscreen	-
Display diagonal	3.7 \
Display resolution	800 x 480 pixels
ROM capacity	512 MB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	Yes
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Certification	CE, FCC, BSMI, VCCI, CCC, RoHS
Product color	Black
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Code 11, Code 128, Code 128A, Code 128B, Code 128C, Code 32, Code 39, Interleaved 2 of 5
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, Small Aztec Code, TLC-39
Rear camera resolution (numeric)	5 MP
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	74 mm
Width	177 mm
Height	40 mm
Weight	- g
