Unitech PA692

- 15 -
Using the MicroSD Memory Card
The PA692 has an expansion slot compatible with a range of MicroSD memory
cards,whichareprimarilyusedtobackuportransferlesanddata.
Using the Hardware
Chapter 2
Inserting a Memory Card
1. Remove the two screws on the MicroSD slot
shield and remove the shield.
2. Insert the MicroSD card with the notched
corner as shown.
3. Push the card into the slot until you feel the MicroSD card click into place.
4. Screw the MicroSD compartment cover back into place.
Removing the Memory Card
1. Remove the two screws from the MicroSD compartment shield and remove
the shield.
2. Press the card in and release. The card pops out.
3. Remove the card from the slot.
