Unitech PA692 User Manual

- 16 -
Using the SIM Card
The PA692 has a slot for a GPRS SIM card inside the battery compartment.
CAUTION! Before installing the SIM card, please backup your data to prevent
data loss because of a low backup battery.
Inserting the SIM card
1. Remove the battery compartment cover and the main battery.
2. Slide the cover of the SIM card slot to the
right to release the latch.
3. Pull open the cover with thumb.
4. Insert the SIM card into the cover with the
notched corner up, and the contact side of
the SIM card faces down.
5. Close the cover over the slot, and then slide
the cover to the left to lock the SIM card.
6. Put the battery back into the battery compartment and replace the battery
compartment cover.

Unitech PA692 Specifications

General

Touchscreen	-
Display diagonal	3.7 \
Display resolution	800 x 480 pixels
ROM capacity	512 MB
Internal memory	0.512 GB
Internal memory type	DDR
Compatible memory cards	MicroSD (TransFlash)
Built-in processor	Yes
Processor frequency	1 GHz
Processor manufacturer	Texas Instruments
Operating system installed	Android
Wi-Fi standards	802.11a, 802.11b, 802.11g
Bluetooth version	2.1+EDR
Certification	CE, FCC, BSMI, VCCI, CCC, RoHS
Product color	Black
Keyboard layout	Alphanumeric
Linear (1D) barcodes supported	Code 11, Code 128, Code 128A, Code 128B, Code 128C, Code 32, Code 39, Interleaved 2 of 5
International Protection (IP) code	IP65
2D (matrix & stacked) barcodes supported	Aztec Code, Composite Codes, MaxiCode, Micro QR Code, MicroPDF417, PDF417, QR Code, Small Aztec Code, TLC-39
Rear camera resolution (numeric)	5 MP
Storage temperature (T-T)	-10 - 50 °C
Operating temperature (T-T)	-20 - 60 °C
Operating relative humidity (H-H)	5 - 95 %
Headphone outputs	1
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.

Weight and Dimensions

Depth	74 mm
Width	177 mm
Height	40 mm
Weight	- g
