Technical Data HPCE Dynamis 500+
Nominal voltage
380V/440V 3ph
Nominal frequency
50Hz/60Hz
Nominal power rating
16 KW – 32,6A @380V/50Hz
19,2 KW – 32,6 A @440V/60Hz
Motor protection type
CLASS F / IP 55
Recommended breaker
50 A, class D or K
Pump type
W5018 HR
Pump oil type
SAE 15W40 ISO VG100 DIN 51524
Pump oil quantity
5 litres (pump requires 1lt per fill)
Nominal water flow
18 lt/min @380V
21 lt/min @440V
Maximum working pressure
500 bar
Nozzle size
030 @ 380V/50 HZ
035 @ 440V/60 HZ
Admissible overpressure
550 bar
Max water intake temperature
40 °C
Weight in kg
186 kg
Dimensions (LXWXH)
108x57x92 cm
Abbreviations HP - High Pressure LP - Low Pressure
HPCE – High Pressure Cleaner Extreme PPE – Personal Protective Equipment
Safety symbols
The below symbols used in this manual indicate actions that should not be ignored, as they may result in
human injuries or damages to the machine.
Electric shock Risk Read carefully BEFORE operating the machine
Risk for persons Helpful tips and hints
Risk for the machine
