Unitronics’s BACnet Gateway User Guide Page 21 of 28

Unitronics

4 CHANGING THE GW-BAC1 IP ADDRESS

4.1 Connect the PC to GW-BAC1 via the Ethernet Port

Figure 27: Ethernet Port Location

 Connect a standard CAT5 Ethernet cable (Straight through or Cross-Over) between the PC and GW-BAC1

 The Default IP Address of GW-BAC1 is 192.168.1.24, Subnet Mask is 255.255.255.0. If the PC and GW-BAC1

are on different IP Networks, assign a static IP Address to the PC on the 192.168.1.xxx network

 Go to > >

 Right-click on Local Area Connection > Properties

 Highlight >

 Select: Use the following IP address

 Click twice

Figure 28: PC IP configuration

Ethernet

Port
