Unitronics’s
BACnet Gate
way User Guide
Page 7 of
28
Unitronics
2.2
C
o
n
n
e
c
t
i
n
g
a
U
n
i
t
r
o
n
i
c
s
P
L
C
t
o
t
h
e
GW
-
B
A
C
1
v
i
a
M
o
d
b
u
s
R
S
-
485
GW
-BAC1 6 Pin Phoenix co
nnector for RS
-485 Device
The 6 pin Phoenix conn
ector is the same for
GW
-BAC1.
Pins 1 through
3 are for Modbus RS-
4
85
devices.
o
The RS-485 GND (Pin 3) i
s not typically co
nnected.
Pins 4 through
6 are for power.
Do not connect power
(wait un
til Section 3.4
).
Figure 2
:
Power and RS-485 Connections
Device Pins
GW
-BAC1 Pin #
Pin assignment
Pin RS-485 +
Pin 1
RS
-485 +
Pin RS-485 -
Pin 2
RS
-485 -
Pin GND
Pin 3
RS
-485 GND
Power In (+)
Pin 4
V +
Power In (-)
Pin 5
V
-
Frame Ground
Pin 6
FRAME GND
6
8
