Universal Audio Apollo Twin X User Manual

Apollo Twin X Hardware Manual 33
Hardware Block Diagram
Apollo Twin X Hardware Block Diagram
V02
INPUT GAIN
10 – 65 dB
INPUT CHANNEL 1
A/D
HEADPHONES OUT
SHARC®
DSP
DRAM
SHARC®
DSP
DRAM
ARM®
PROCESSOR
1/4” TRS
MIXER
CLOCKING / SYNC
SYSTEM CONTROL
ø
LOW-CUT
ON/OFF
POLARITY
CONTROL
OUTPUT
VOLUME
S/PDIF, ADAT/SMUX
OPTICAL INPUT
THUNDERBOLT
TM
3
HOST INTERFACE
DSP
EEPROM
INTERNAL
TALKBACK MIC
SHARC®
DSP
DRAM
SHARC®
DSP
DRAM
TYPE-C
HI-Z AUTOMATICALLY
SELECTED IF PLUG
INSERTED IN HI-Z JACK
VCO
CLOCK
OSCILLATOR
PLL
AUDIO
CLOCKS
MONITOR OUTPUTS L/R
D/A
MONITOR OUT
1/4” TRS
LINE OUTPUTS 3-4
D/A
+4dBu / -10dBV
SELECT
PAD
LINE OUT
Pad Works on
Stereo Pairs
1/4” TRS
HI-Z IN
MIC IN
MIC PAD
IN/OUT
+48V ON/OFF
PAD
MIC/LINE
SELECT
LINE IN
XLR FEMALE
1/4” TS
1/4” TRS
MIC-LINE/HI-Z
SELECT
+48V
Unison™
IMPEDANCE
SWITCHING
(HI-Z)
Unison™
IMPEDANCE
SWITCHING
(MIC)
DSP DSP
HEADPHONES L/R
TOSLINK
DUO
QUAD
TOP PANEL
INPUT GAIN
10 – 65 dB
INPUT CHANNEL 2
A/D
ø
LOW-CUT
ON/OFF
POLARITY
CONTROL
DSP
MIC IN
MIC PAD
IN/OUT
+48V ON/OFF
PAD
MIC/LINE
SELECT
LINE IN
XLR FEMALE
1/4” TRS
+48V
Unison™
IMPEDANCE
SWITCHING
(MIC)
OUTPUT
VOLUME
D/A
DSP
