You can monitor multiple sources at the same time. Enable all sources that you want to
route to monitor outputs and headphones.
Press the MONO button so it is lit blue to listen to the inputs panned to the center. By default,
inputs are routed in stereo, so input 1 and 3 are routed to the left output, and input 2 and 4
are routed to the right output.
You can still hear direct audio from the inputs if IN sources are enabled, even if no OUT
sources are enabled for monitoring. In this scenario you can monitor your input sources,
even if you are not monitoring any output from the audio software, or when Volt is not
connected to a computer.
When any combination of both IN and OUT sources are enabled, the volume from your
audio software is slightly reduced so you can clearly hear your input signals.
The monitor source buttons work as described below.
Monitor
Source
Button
Enabled Disabled
IN 1-2 Hardware inputs 1-2 are routed directly
to the monitor and headphone outputs,
and also to the audio software.
Hardware inputs 1-2 are routed to the
audio software, but not directly to the
monitor and headphone outputs.
IN 3-4 Hardware inputs 3-4 are routed directly
to the monitor and headphone outputs,
and also to the audio software.
Hardware inputs 3-4 are routed to the
audio software, but not directly to the
monitor and headphone outputs.
OUT 1-2 Audio software outputs 1-2 are routed
to the monitor and headphone outputs.
Audio software outputs 1-2 are not
routed to monitor and headphone
outputs.
OUT 3-4 Audio software outputs 3-4 are routed
to the monitor and headphone outputs.
Audio software outputs 3-4 are not
routed to monitor and headphone
outputs.
