Note: The monitor outputs are not powered. You will need to connect the cables to either
powered speakers or an amp with speakers.
(14) Line Outputs
Use the line outputs for monitoring unattenuated audio directly from the software. Audio can be
assigned to these outputs in your software. These are ¼” balanced outputs. See (11) Monitor
Source Buttons for related information.
Line Outputs 1-2 typically carry the main outputs from your software.
Line Outputs 3-4 must be specifically assigned as outputs from your software. These can
be used for various monitoring purposes.
(15) Line 3-4 Inputs
Connect input sources for line inputs 3-4 here. These are ¼” balanced inputs designed for line-
level sources, such as synths, external sound modules, or other line-level sources.
Note: There are no gain controls on the line 3-4 inputs. Any level controls must be configured in
your software.
(16) MIDI I/O
You can connect a MIDI device to Volt with standard 5-pin MIDI DIN cables. Connect the MIDI
OUT of your device to the MIDI IN on Volt, and the MIDI IN of the device to the MIDI OUT on Volt.
You may not need to make both connections. For example, a MIDI controller might only be
connected to the MIDI IN on Volt, and a MIDI sound module might only be connected to the MIDI
OUT from Volt.
(17) USB-C
Connect Volt to a USB 2.0 (or higher) port on your computer with a USB-C to USB-A cable
(included), or with another cable.
