Upright AB38 Operator's Manual

Maintenance
Operation Manual Page 9
M AINTENANCE
WARNING
!
!
Never perform service while the platform is elevated.
H YDRAULIC F LUID
The hydraulic fluid reservoir is located in the chassis door.
Figure 5: Hydraulic Fluid Reservoir and Dipstick
NOTE: Never add fluid if the platform is elevated.
C HECK H YDRAULIC F LUID
1. Make sure that the platform is fully lowered.
2. Open the chassis door.
3. Remove the filler cap from the hydraulic fluid reservoir.
4. Check the fluid level on the dipstick on the filler cap.
5. Add the appropriate fluid to bring the level to show on
the dipstick. See “Specifications” on page 14
Filler Cap
