26
BOSSES & BUSHES
1
2
D1
D2
L2
L1
STANDARD BUSH CODE: SB-XXX XXX
e.g. SB-030040
THE BUSH MUST FILL THE COMPLETE LENGTH OF L1.
HOWEVER, IT IS ACCEPTABLE TO MAKE UP THR TOTAL LENGTH L1 BY USING
MORE THAN ONE BUSH
ALWAYS USE GENERAL PURPOSE GREASE ON YELLOW SURFACE OF THE
BUSH .
THE PIN MUST BE FREE FROM SCORES—IF IN DOUBT, REPLACE THE PIN
D1 (MM)
L1 (MM)
