Upright TL37 - Page 130

Maintenance Torque Specifications
Index of Fasteners
PN Description qty Grade
058502-045 M6 x 45mm SOCKET CAP DIN 912 ZINC PLATED 8 12.9
058502-075 M6 x 75mm SOCKET CAP DIN 912 ZINC PLATED 3 12.9
058502-090 M6 x 90mm SOCKET CAP DIN 912 ZINC PLATED 2 12.9
058503-050 M8 x 50mm SOCKET CAP DIN 912 ZINC PLATED 4 12.9
058503-055 M8 x 55mm SOCKET CAP DIN 912 ZINC PLATED 2 12.9
058503-060 M8 X 60mm SOCKET CAP DIN 912 ZINC PLATED 6 12.9
058503-090 M8 X 90mm SOCKET CAP DIN 912 ZI NC PLATED 2 12.9
058510-020 M8 x 20mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
058510-025 M8 X 25mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
058510-030 M8 x 30mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
058510-040 M8 x 40mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
11-0838 M16 x 130mm H.T. HEX BOLT DIN 931 ZINC PLATED 2 10.9
11-2411 M16 NYLOC NUT DIN 985 GRADE 10 2 10
11-3429 M16 x 90 H.T. HEX BOLT DIN 931 SELF COLOUR 16 12.9
11-3430 M16 X 80 SOCKET CAP DIN 912 SELF COLOUR 16 12.9
11-3432 1 1/4" FLAT WASHER ZINC PLATED 8 BS4320
11-3442 M12 x 170mm H.T. HEX BOLT DIN 931 ZINC PLATED 2 8.8
500532-010 M6 x 10mm CSK SOCKET DIN 7991 ZINC PLATED 2 10.9
500532-020 M6 X 20mm CSK SOCKET DIN 7991 ZINC PLATED 2 10.9
500532-030 M6 x 30mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
500532-035 M6 x 35mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
500532-040 M6 x 40mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
500532-045 M6 x 45mm CSK SOCKET DIN 7991 ZINC PLATED 5 10.9
500532-055 M6 x 55mm CSK SOCKET DIN 7991 ZINC PLATED 1 10.9
500532-060 M6 x 60mm CSK SOCKET DIN 7991 ZINC PLATED 2 10.9
500595-020 M8 x 20mm BUTTON HEAD SOCKET ISO 7280 5 10.9
501253-016 M6 X 16 SOCKET CAP DIN 912 ZINC PLATED 10 12.9
508247-005 M5x 20 PENNY WASHER ZINC PLATED 9
508247-006 M6x 25 PENNY WASHER ZINC PLATED 14
508247-008 M8x 25 PENNY WASHER ZINC PLATED 12
508248-006 M6X 30 PENNY WASHER ZINC PLATED 17
508251-000 4.2mm POP RIVET 9
508252-040 M4 x 40mm CSK SOCKET DIN 7991 ZINC PLATED 2 12.9
508255-000 32mm P-CLIP 1
23-0031 die spring - for loa 2
056060-030 M10 X 30mm H.T . HEX SET DIN 933 ZINC PLATED 4 8.8
056060-070 M10 X 70mm H.T. HEX BOLT DIN 931ZINC PLATED 1 8.8
058503-100 M8 X 100mm SOCKET CAP DIN 912 ZINC PLATED 2 12.9
058503-040 M8 X 40mm SOCKET CAP DIN 912 ZINC PLATED 2 12.9
500532-016 M6 X 16 CSK SOCKET DIN 7991ZINC PLATED 2 10.9
500532-070 M6 x 70mm CSK SOCKET DIN 7991 ZINC PLATED 2 10.9
058510-060 M8 x 60mm CSK SOCKET DIN 7991 ZINC PLATED 4 10.9
058501-012 M5 x 12mm SOCKET CAP DIN 912 ZINC PLATED 2 12.9
503761-001 1" x 1.8 mm LIGHT PATTERN FLAT WASHER ZINC 10 BS4320
48
