13
Reverse the control lever
until the slewing action re-
turns.
& Read Operators
Manual
Are all the
Outriggers under load? (LEDs)
Slew will not operate (Motor Running)
NO
Has the correct control switch
been selected? (ground/ basket)
YES
Select appropriate control
& Read Operators
Manual
NO
YES
Reset the Outriggers
until all LEDs are
Illuminated
& Read Operators
Manual
Has the slew reached the slew stop?
NO
YES
Is there enough Oil in the tank?
NO
Top up Oil Level
& Read Operators
Manual
YES
If further advice is
required, consult
an
UpRight
Technician.
Is there an obstruction
Preventing the slewing action?
Remove obstruction, or
reposition
& Read Operators
Manual
NO YES
NO CHANGE
FAULT FINDING MATRIX
To Next Page
